Our new Heritage bi fold door has been designed to work in perfect harmony with our existing Heritage door and window range. Offering a traditional stepped profile detail with slim sightlines.

The Heritage bi fold door is a versatile alternative to classic Heritage French doors with side lights.

Delivering the perfect combination of retro steel style design with modern strength and exceptional thermal performance our Heritage bi fold door system is capable of opening up an entire wall to integrate outdoor and indoor living space.

Heritage steel style bi fold patio doors - closed

Key Features

  • Smooth easy operation
  • Aluminium that looks like steel
  • Approved replacement for listed buildings by many council authorities
  • Ultra slim framework
  • A fraction of the cost of steel
  • Matching Heritage windows and doors





Rated 5.0 out of 5 Andrew Beevers

...trumps the 'Crittall' type systems on thermal performance and cost.
The grasp of the importance of design and quality of manufacture from the Marlin Team is second to none.



Read the rest of these and our other 5 star reviews left on Google




Product Information

Full List of Features

  • Designed to work in perfect harmony with our classic slim Heritage windows and doors
  • Quality and style - Panels with actual transoms and individual double glazed units – not stick on bars
  • Maximum panel width – 1000mm (minimum – 700mm)
  • Maximum panel height – 2200mm (minimum – 1800mm)
  • Flexible opening configurations – open in or open out
  • Available with a flush threshold or projection cill
  • Extensive range of RAL colours, textured and anodised finishes
  • Stunning range of handle designs in traditional or contemporary styles
  • Premium security with robust locking mechanisms with high security Avocet ABS cylinder as standard
  • Fully compliant with the requirements of Building Regulations Document L 2010
  • Excellent thermal properties. High performance glass options for all requirements
  • Aluminium that looks like steel
  • Approved replacement for listed buildings by many council authorities
  • Ultra slim framework
  • A fraction of the cost of steel
Aluminium Heritage Bi fold Door Profile
Heritage steel style bi fold patio doors

Flexible Design Options

This smooth and easy to operate bi fold door with robust roller and panel guides can be tailored to your specific requirements.

Use flexible opening options and multiple transom configurations to create your authentic time-honored design.

To complement our Heritage bi fold door we have commissioned authentic hardware in various styles and finishes and if required these can be powder coated to match the frame work.

secure by design sliding patio door locks

Peace of mind premium security

A tough multi-point locking mechanism protected with the Avocet ABS euro cylinder further enhances the appeal of this elegant bi fold door manufactured to our usual industry leading high standards.

The clever locking system of the Avocet ABS® diamond grade cylinder knows when it has been snap attacked and fires into action to create a robust barrier to entry. The patented Active Cam TechnologyTM is hidden deep within a solid Molybdenum cam which is 20% stronger than steel, and delivers ultimate resistance against a lock snapping attack and snap/twist manipulation. All of the snap technology is focused on the outside part of the lock only. This makes sure that maximum strength is given to the inner part of the lock - the part that has the job of securing your door.





Rated 5.0 out of 5 Malcolm Sykes

The guys did an excellent job today removing my old doors and then installing my new bi-folds... old doors and frame out cleanly and then installed the new doors very neatly. All in all an excellent job well done. The new bi-fold doors look really good!



Read this and our other 5 star reviews left on Google




Glazing and frame colour choice

COLOURS AND GLAZING

Our aluminium profiles are polyester powder coated by our systems suppliers using the very latest paint application techniques guaranteed for 25 years.

SGG Planitherm sealed glass units complete our leading combination of products and finishes.

Read More





Rated 5.0 out of 5 Stephen Jackson

Thank-you Marlin Windows for a great job! You designed and built all the windows in our renovation project including sliding doors and bi-folds with care and consideration. From our first contact with Adrian through to the final fitting, the service was exceptional...



Read the rest of this and other Reviews of Marlin Windows left on Google



Featured Bi Fold Door Projects:



Rated 5.0 out of 5 Malcolm Sykes

Many thanks for supplying and installing my new bi-fold doors. The guys did an excellent job today removing my old doors and then installing my new bi-fold doors. They managed to get the old doors and frame out cleanly and then installed the new doors very neatly.
All in all an excellent job well done. The new bi-fold doors look really good!



Read this and our other 5 star reviews left on Google



On TV



Our low profile superslim frame low threshold bi-fold doors featured on Love Your Home & Garden With Alan Titchmarsh (Swindon episode)
broadcast on ITV on January 15th 2019

Watch the programme highlights in less than 2 minutes below



"it's like a dream home" says homeowner Nina

"So easy to open" says Alan

"so slim and so elegant, barely any step we're talking millimetres" says architect Ewald Van Der Straeten

Document Downloads

File Type Document Description Download Document
Adobe PDF Smart
Sliding and Slide & Fold Brochure
Download (13.2 MB)

Technical Specification

Technical Performance

U Value 1.5W/m2K using a 1.0 centre pane
Air Class 2, 450Pa
Water Class 8A, 450Pa;
Wind Class 3, 1200Pa

Design Specification

Frame Width 88mm
Frame Depth 76 or 82mm
Glass 24, 28, 32 or 40mm double or triple glazed units
Typical Sight Line 94mm for Slide and Fold Door
Max Sash Height 2200mm
Max Sash Width 1000mm
Max Sash Weight 100KG

The Buyers Guide To Bi-Fold Doors

guide to how to buy bi-fold doors

Read our guide to buying bi-folding doors for your home

Integral Blinds For Bi-Fold Doors

built in integral blinds for bi-fold doors

All bi-fold doors can be fitted with built in integral blinds

How To Guide To Low & Flush Thresholds

guide to how to get low & flush easy wheelchair access thresholds

Read our guide to achieving a fabulous seemless appearance of a flush threshold
