Schüco ASE 60 Sliding Doors

Sliding and lift-and-slide system with excellent thermal insulation values and slim face widths

Key Features

Highest water tightness classification (Class 9A)

Extremely slim sightlines 90mm

Lowest U values in the market – low as 1.0 Wm2k

Large panel sizes up to 3500mm wide 3500mm high

Effortless glide operation

Security tested PAS 24 and RC2

Make the most of your inside-outside space

Unique Outlook Without Compromises.

The modular and scalable Schüco ASE 60 sliding and lift-and-slide system boasts excellent thermal insulation values, slimline face widths and comprehensive solutions in terms of design and comfort.

A special highlight is that the sliding system can be individually configured in terms of comfort and design. Optional fittings components such as the Schüco SmartStop and Schüco SmartClose security and comfort technology ensure maximum ease of use. A slimline interlock section allows inside and outside to merge together, while the level threshold meets everyday needs for ease of access.

The profile system retains its high-quality design even when open thanks to the concealed fittings components.

The certified burglar resistance of the sliding and lift-and-slide systems ensures increased security requirements are met.

Product Information

SYSTEM / MATERIAL   –   Aluminium

Min. vent height   –   1334 mm

Max. vent height   –   3500 mm

Min. vent width   –   630 mm

Max. vent width   –   3500 mm

Vent frame face width   –   82 mm

Min. face width of interlocking section   –   40 mm

Min. system basic depth   –   140 mm

Barrier-free (≤) 20 mm   –   Yes

Uw value of window (≥)   –   1.1 W/(m²·K)

Max. sound reduction index Rwp   –    41 dB(A)

Watertightness   –   E 900​

Burglar resistance   –   Up to RC 2

Operating type   –   manual

Document Downloads

Schüco ase 60 sliding doors – BROCHURE

NEW DIMENSIONS OF DESIGN FREEDOM

COLOURS AND GLAZING

Our aluminium profiles are polyester powder coated by our systems suppliers using the very latest paint application techniques guaranteed for 25 years.

Fully compliant to the latest June 2022 building regulations our standard double glazing is the exceptional light transmitting, energy saving ClimaGuard® A+ low emissivity (Low-E) glass manufactured by Guardian Glass.



”…really helpful with all my technical queries, which helped make sure my orders were mm perfect and the doors all went in smoothly…

They look great – will do it all again in our next house!”

 Nicholas Kitchen

Latest projects

STEEL REPLACEMENT WINDOWS

Shireburn House – Lancashire

CONTEMPORARY WINDOWS

Clifton Road – Ilkley

Why choose Marlin?

Reasons why you should expect 100% satisfaction.

Quality Control

We believe that our quality standards are unrivalled. Our manufacturing processes and activities are monitored with well defined controls and inspection procedures are performed by trained personnel.

Care

We respect you, your property and your project taking care over each detail from order to delivery to your post installation satisfaction.

Project Focus

Your project is important to us. We manufacture to your made to measure requirements so that we get it exactly right. See example case studies of our project work.

Frequently Asked Questions

If you require any support, please don’t hesitate to review our FAQ’s below or drop us a message on our contact form here

What are the key features of the Schüco ASE 60 Sliding Door?

Our Schüco ASE 60 Sliding Doors offer exceptional thermal performance with U-values as low as 1.1 W/m²·K. They feature ultra-slim sightlines starting at just 40mm, allowing for expansive glass areas and unobstructed views. The system supports large panel sizes up to 3500mm wide and 3500mm high, ensuring a seamless connection between indoor and outdoor spaces. Optional enhancements include Schüco SmartStop and SmartClose for improved user comfort and security.

Are these doors suitable for various building types?

Yes, the Schüco ASE 60 Sliding Doors are versatile and suitable for both residential and commercial applications. Their modular design allows for customisation to meet specific architectural requirements, including single, double, or triple track configurations. The system’s high thermal insulation and security features make it ideal for energy-efficient homes and buildings requiring enhanced safety standards.

What customisation options are available?

We offer a wide range of customisation options for the Schüco ASE 60 Sliding Doors. Clients can choose from over 200 RAL colours, including dual finishes, to match their aesthetic preferences. The system supports various glazing thicknesses up to 40mm, accommodating both double and triple glazing. Additionally, the doors can be configured with different opening types, including fixed or open corner designs, to suit diverse architectural styles.
